- Large surface, ground cast-iron tables for stability and added support when feeding longer stock.
- Heavy-duty, three-knife cutter head for clean, fast, superior finish cuts.
- Jackscrew system for quick, easy knife adjustment.
- Large, heavy-duty, center-mounted cast-iron fence with 90° and 45° positive stops.
- Independent in-feed and out-feed table adjustment hand wheels.
- 4” dust collection outlet included.
- 2 hand paddle style push blocks included.
- Extra long 55 1/8" tables.
Table size 7 1/4" x 55 1/8" (184 x 1402 mm)
Maximum cutting width 6" (152 mm)
Maximum cutting depth 1/2" (13 mm)
Rabbeting capacity 1/2" (13 mm)
Fence size 4" x 29" (102 x 737 mm)
Cutter head speed 5000 RPM
Number of knives 3 - 80-075L HELICAL - 80-075L HC
Dimensions (l x w) 23 1/2" x 13" (597 x 330 mm)
Motor 1 HP, 110/220 V, 13/6.5 A
Weight 235 LBS (107 kg)
